Kamvas 24
Kamvas 24 Plus
Kamv a s 2 4
SIMPLE, B U T
POWE R F U L
D e l i c a t e
P r e s e n t a t i o n
o f
V i v i d
D e t a i l s.

Stunning details on the screen

  • 23.8inch screen

  • 2.5K resolution

  • 178° viewing angle

  • 120% sRGB color gamut

  • 16.7M(8bit) display colors

  • 1000:1 contrast ratio

A new level of clarity.

With a 23.8inch wide screen, Kamvas 24 not only ensures clear and crisp picture presentation but also prevents interruptedly zooming in or out of the canvas.

23.8 inch

2.5K crystal clear images.

120% sRGB color gamut together with 16.7 million display colors ensure crystal clear images on this 2.5K IPS display. Everything you see and draw on this display is lively and colorful.

2560 x 1440

Resolution

120% sRGB

Gamut

16.7M(8bit)

Display Color

View your creation from different angle.

178° wide viewing angle ensures clear and vivid visual effects of your works even when looking at the screen from sideways.

Viewing Angle

178°

Draw what you want

Your creativity can be fully presented.

To bring users more realistic drawing experience, digital pen PW517 that developed based on PenTech3.0 is introduced. With a stable and improved pen nib, the digital pen ensures flexible and natural drawing experience.

Anti-friction Silicon Grip

Dual Programmable Button

Set your imagination free.

Kamvas 24 features 8192 levels of pressure sensitivity and rapid report rate, allowing users to draw lines with different widths and thickness. Your work hence can be more vibrant.

8192 levels

＞220PPS

±60° tilt support

Tilt your pen and feel the flexibility.

Kamvas 24 enables users to tilt the pen at about ±60° to realize various drawing techniques such as shading, sketching or edging.

Maximum creation

Ports for more possibilities.

Kamvas 24 features two USB-C ports, one for three-in-one cable and one for USB-C to USB-C cable, allowing users to explore more possibilities via the connection to computer, laptop, and Android phone/ tablet. A USB-A port is also designed for connecting keyboard, USB flash disk, etc.

Three-in-one cable (HDMI mode):

USB-C to USB-C cable (DP mode):

* A three-in-one cable is needed for power supply when connecting via the USB-C to USB-C cable.

* Please note that USB-C ports on phones/ tablets should support DP1.2. Besides, only phones/tablets with desktop mode can support full screen display.

* List of Compatible Android devices >>

Accessory to boost productivity.

Users can tilt the stand to find a more comfortable position during creation. Besides, a mini keydial KD100 is recommended to work together with the pen display for better productivity.

*Mini Keydial KD100 is not included in the package and need to be purchased separately.

Strong compatibility.

Kamvas 24 is compatible with Windows, macOS, Linux OS and Android, as well as most mainstream design and drawing software.

*The terms HDMI, HDMI High-Definition Multimedia Interface, HDMI Trade dress and the HDMI Logos are trademarks or registered trademarks of HDMI Licensing Administrator, Inc.

Kamvas 24

Kamvas 24 Plus

Appearance

  • Color： Dark Gray
  • Dimension： 604.2 x 358 x 21~28.3mm (Without Stand)
  • Working Area： 526.85 x 296.35mm
  • Net Weight： 5.6Kg (With Stand)
  • Touch： -
  • Stand： Adjustable Stand 20°~80°
  • Video Interface： USB-C, Full-Featured USB-C
  • Color： Dark Gray
  • Dimension： 604.2 x 358 x 21~28.3mm (Without Stand)
  • Working Area： 526.85 x 296.35mm
  • Net Weight： 5.6Kg (With Stand)
  • Touch： -
  • Stand： Adjustable Stand 20°~80°
  • Video Interface： USB-C, Full-Featured USB-C

Screen

  • Resolution： 2560 x 1440 (16:9) QHD
  • LCD Type： IPS
  • AG Glass： Anti-glare matte film
  • Full Lamination： NO
  • Contrast Ratio： 1000:1
  • Brightness： 220cd/m2 (Max.)
  • Response Time： 14ms
  • Viewing Angle： 89°/89°(H)/89°/89°(V) (Typ.)(CR＞10)
  • Gamut Volume： 85%NTSC/120% sRGB
  • Display Color： 16.7M (8bit)
  • Resolution： 2560 x 1440 (16:9) QHD
  • LCD Type： IPS
  • AG Glass： Anti-glare etched glass
  • Full Lamination： Full Lamination
  • Contrast Ratio： 1200:1
  • Brightness： 220cd/m2 (Max.)
  • Response Time： 14ms
  • Viewing Angle： 89°/89°(H)/89°/89°(V) (Typ.)(CR＞10)
  • Gamut Volume： 97%NTSC/140% sRGB
  • Display Color： 16.7M (8bit)

Technical Specifications

  • Digital Pen： PW517
  • Pen Technology： Battery-Free Electromagnetic Resonance
  • Pen Resolution： 5080 LPI
  • Pressure Sensitivity： 8192Levels
  • Tilt Support： ±60°
  • Sensing Height： 10mm
  • Report Rate： ＞220PPS
  • Accuracy： ±0.3mm (Center) ±2mm (Corner)
  • Press Keys： -
  • Digital Pen： PW517
  • Pen Technology： Battery-Free Electromagnetic Resonance
  • Pen Resolution： 5080 LPI
  • Pressure Sensitivity： 8192Levels
  • Tilt Support： ±60°
  • Sensing Height： 10mm
  • Report Rate： ＞220PPS
  • Accuracy： ±0.3mm (Center) ±2mm (Corner)
  • Press Keys： -

Operating Conditions

  • Input Voltage： AC 100-240V, 50/60Hz
  • Output Voltage： 19V 3A
  • Power Consumption： ≤20W
  • Standby Consumption： ≤0.3W
  • Working Temp. and Humidity： 0-40°C 、 20-80%
  • Storage Temp. and Humidity： -20°C~60°C, 10-90%
  • Input Voltage： AC 100-240V, 50/60Hz
  • Output Voltage： 19V 3A
  • Power Consumption： ≤20W
  • Standby Consumption： ≤0.3W
  • Working Temp. and Humidity： 0-40°C 、 20-80%
  • Storage Temp. and Humidity： -20°C~60°C, 10-90%

OS Compatibility

  • Windows 7 or later,
    macOS 10.12 or later,
    Android(USB3.1 DP1.2 or later)
    Linux
  • Windows 7 or later,
    macOS 10.12 or later,
    Android(USB3.1 DP1.2 or later)
    Linux

Model

  • GS2401
  • GS2402

Model Comparison
