Kamvas Pro 24(4K)

Just Powerful

A feast of
lively colors

4K screen to expand your viewing experience.

The screen of Kamvas Pro 24(4K) is as large as 23.8inch, which allows users to split the screen like having two monitors and hence ensure a more efficient device for creation. Besides, 4K UHD resolution enhances the overall display quality, allowing picture to be displayed more naturally and clearly.
  • 4K
    Resolution
  • 23.8 inch
    Panel Size

All for true-to-life colors.

With the color depth jumps to 10bit (8Bit+FRC), Kamvas Pro 24(4K) is able to display 1.07 billion true-to-life colors. The 140% sRGB wide color gamut of this QLED display also guarantees users unprecedented viewing experience.
  • 1.07B(8bit+FRC)
    Display Color
  • 140% sRGB (QLED)
    Gamut

Paper-like texture for natural and accurate rendering.

Thanks to the full lamination technology, there is no air gap between the LCD screen and glass, which effectively reduces the parallax and increases transmittance. Additionally, the anti-glare glass not only alleviates the reflection but also ensures more natural and pen-on-paper drawing experience.
  • Full Lamination
  • Anti-Glare Etched Glass

High display quality with HDR technology.

Kamvas Pro 24(4K) is equipped with the HDR technology that can automatically adjust the brightness, color, and contrast ratio of the screen, providing a more dynamic way to improve the overall image quality.

Express your creative
thoughts freely

Natural and stable pen-on-paper drawing.

Battery-free digital pen PW517 that is developed based on PenTech3.0 enables more accurate and flexible strokes. Two programmable buttons on the digital pen are designed to facilitate your creation. This digital pen can also be used to adjust the parameters of the OSD menu, such as the brightness, color temperature, etc.
Anti-friction Silicon Grip
Dual Programmable Button
felt pen nib

Experience more with the new felt pen nib

Kamvas Pro 24(4K) is equipped with 5 standard pen nibs and 5 felt pen nibs to meet the needs of different users. Made of fiber material, the felt pen nib is softer and has stronger friction than the standard pen nib, bringing users unique pen-on-paper drawing experiences.

Ingenious ideas can be presented immediately.

Thanks to the 8192 levels of pressure sensitivity, lines with different widths and saturation can be produced naturally. In addition, ±60° tilt support and 300PPS report rate allow users to capture every input immediately and organically.

  • 300PPS report rate

  • 8192 levels of pressure sensitivity

  • ±60° tilt support

Especially designed for better productivity

KD100, a perfect match for digital creation.

There is no press key equipped on Kamvas Pro 24(4K). Instead, a mini keydial KD100 that comes with the pen display brings great flexibility to users to control the canvas or adjust the brush size. 18 programmable press keys are designed to achieve an efficient and streamlined workflow.
*Mini keydial KD100 is included in the package.

Find your most comfortable position.

Users can tilt the pen display to a 20-degree angle by unfolding the integrated stands on the back of the pen display. Monitor arm ST410/ST420 and an adjustable stand ST100A are also optional for you to find the most suitable angle.
ST410/ST420/ST100A is not included in the package and need to be purchased separately.

Abundant ports for easy connection.

Kamvas Pro 24(4K) is equipped with various ports such as HDMI, DP, USB-C, USB-A, etc., which not only support the connection to computer, Android phone/tablet but also to keyboard, USB flash disk, earphone, etc.
3.5mm
headphone jack
USB-A 2.0
USB-A 2.0
Power button
Power port
USB-C
DP
HDMI
  • Connect to earphone
  • Connect to keyboard
  • Connect to mobile phone

Kamvas Pro 24(4K)

Kamvas Pro 24

Appearance

  • Color: Black
  • Dimension: 589.2 x 364 x 22.7mm
  • Working Area: 527.04 x 296.46mm
  • Net Weight: 6.3Kg
  • Touch: -
  • Stand: Integrated Stand 20°
  • Video Interface: HDMI,DP,USB-C,DC,USB-A 2.0 x 2,3.5mm headphone jack
  • Color: Black
  • Dimension: 659 x 391 x 25mm
  • Working Area: 526.85 x 296.35mm
  • Net Weight: 6KG(With Stand)
  • Touch: dual touch bar
  • Stand: adjustable stand 20°~80°
  • Video Interface: HDMI、DP、VGA

Screen

  • Resolution: 3840 x 2160(16:9) UHD
  • LCD Type: IPS
  • AG Glass: Anti-glare etched glass
  • Full Lamination: YES
  • Contrast Ratio: 1200:1
  • Brightness: 220cd/m2 (Max.)
  • Response Time: 10ms
  • Viewing Angle: 89°/89°(H)/89°/89°(V) (Typ.)(CR>10)
  • Gamut Volume: 140% sRGB
  • Display Color: 1.07B(10bit)
  • Resolution: 2560 x 1440(16:9)QHD
  • LCD Type: IPS
  • AG Glass: Anti-glare etched glass
  • Full Lamination: YES
  • Contrast Ratio: 1000:1
  • Brightness: 220cd/m2
  • Response Time: 14ms
  • Viewing Angle: 89°/89°(H)/89°/89°(V) (Typ.)(CR>10)
  • Gamut Volume: 120% sRGB
  • Display Color: 16.7M(8bit)

Technical Specifications

  • Digital Pen: PW517
  • Pen Technology: Battery-Free Electromagnetic Resonance
  • Pen Resolution: 5080LPI
  • Pressure Sensitivity: 8192Levels
  • Tilt Support: ±60°
  • Sensing Height: 10mm
  • Report Rate: >300PPS
  • Accuracy: ±0.3mm(center) ±3mm(corner)
  • Press Keys: -
  • Digital Pen: PW517
  • Pen Technology: Battery-Free Electromagnetic Resonance
  • Pen Resolution: 5080 LPI
  • Pressure Sensitivity: 8192Levels
  • Tilt Support: ±60°
  • Sensing Height: 10mm
  • Report Rate: >200PPS
  • Accuracy: ±0.5mm(Center) ±3mm(Corner)
  • Press Keys: 20 programmable press keys

Operating Conditions

  • Input Voltage: AC 100-240V, 50/60Hz
  • Output Voltage: 19V 3A
  • Power Consumption: ≤35W
  • Standby Consumption: ≤0.4W
  • Working Temp. and Humidity: 0-40°C . 20-80%
  • Storage Temp. and Humidity: -20°C~60°C. 10-90%
  • Input Voltage: AC 100-240V, 50/60Hz
  • Output Voltage: 12V 3A
  • Power Consumption: ≤18W
  • Standby Consumption: ≤0.3W
  • Working Temp. and Humidity: 0-40°C, 20-80%
  • Storage Temp. and Humidity: -20°C~60°C, 10-90%

OS Compatibility

  • Windows 7 or later
    macOS 10.12 or later
    Android(USB3.1 DP1.2 or later)
    Linux
  • Windows 7 or later
    macOS 10.12 or later
    Linux

Model

  • GT2401
  • GT-240

Model Comparison
